Comp Cams Magnum Hydraulic Lift Camshaft – Optimized For Street Performance

Description

Brand: COMP Cams
Manufacturer’s Part Number: 33-230-4
Part Type: Camshafts
Product Line: COMP Cams Magnum Hydraulic Camshafts
Automotive Fittings Part Number: CCA-33-230-4
UPC: 036584520290
Cam Style: Hydraulic flat tappet
Camshaft Use: Street/Strip
Basic Operating RPM Range: 2,000-6,000
Intake Duration at 050 inch Lift: 230
Exhaust Duration at 050 inch Lift: 230
Duration at 050 inch Lift: 230 int./230 exh.
Advertised Intake Duration: 280
Advertised Exhaust Duration: 280
Advertised Duration: 280 int./280 exh.
Intake Valve Lift with Factory Rocker Arm Ratio: 0.530 in.
Exhaust Valve Lift with Factory Rocker Arm Ratio: 0.530 in.
Valve Lift with Factory Rocker Arm Ratio: 0.530 int./0.530 exh.
Lobe Separation (degrees): 110
Remanufactured: No
Computer-Controlled Compatible: No
Grind Number: FB 280H-10
Valve Springs Required: Yes
Quantity: Sold individually.
Notes: Will not fit factory Ford FE solid lifter engine blocks.
Description:
Designed for hot street/strip cars, COMP Cams Magnum series cams require a higher compression ratio, rear-end gear ratio, and stall torque converter than stock. With a very aggressive profile, these Magnum hydraulic camshafts provide maximum top-end performance for your high performance car.
