Wilwood Dynapro Front Brake Kit – Dust-Boot Equipped Caliper System With Rotors

Description

Brand: Wilwood Disc Brakes
Manufacturer’s Part Number: 140-13377
Part Type: Disc Brake Kits
Product Line: Wilwood DynaPro Dust-Boot Pro Series Front Brake Kits
Automotive Fittings Part Number: WIL-140-13377
UPC: 889545020229
Position: Front
Front Rotor Included: Yes
Front Rotor Style: Solid surface
Front Rotor Construction: Vented
Front Rotor Diameter: 11.00 in./279.40mm
Front Rotor Thickness (in.): 0.81 in.
Brake Rotor Bolt Pattern (in.): Dual 5 x 4.50 in./5 x 4.75 in.
Brake Rotor Bolt Pattern (mm): Dual 5 x 114.30mm/5 x 120.65mm
Rear Rotor Included: No
Front Caliper Included: Yes
Front Caliper Piston Quantity: Four
Front Caliper Material: Forged billet aluminum
Front Caliper Color: Black
Rear Caliper Included: No
Brake Pads Included: Yes
Friction Material Name: BP-10
Parking Brake Provision: No
Minimum Recommended Wheel Diameter (in.): 14 in.
Front Spindles Included: No
Master Cylinder Included: No
Brake Booster Included: No
Remanufactured: No
Brake Hoses Included: No
Quantity: Sold as a kit.
Notes: Includes 1/2 in.-20 wheel studs. Kit includes hubs, brake pads, and mounting hardware. Bolt circles for hubs are 5 x 4.50 and 5 x 4.75 in. Factory disc spindle. Not applicable to 4 lug vehicles.
Description:
Wilwood DynaPro Big Brake front brake kits allow you to enhance conventional non-ABS spindles on machines providing big brake stopping power. These kits were developed for when dust-booted pistons are appropriate to provide added protection against dirt and debris in low temperature areas and rough environments. A full range of caliper finish and rotor designs provide options to individualize the style and preferences of any enthusiast. Kits come complete with calipers, rotors, hub assembly, brackets and hardware.
